Hybrid X
Resource center
- ANG brochure 2024-2025 (113 MB)
Make sure all your hard work does not go to waste, wrap silage bales with the HYBRID X XTRACTOR™ for round and square bales. Combining the features of both a round and square bale wrapper, this model delivers dramatically higher efficency ensuring perfectly wrapped bales every time. Its versatility makes it ideal for custom operators.
Features and options (ask your dealer for combos available)
- 1.
XTRACTOR™ final bale push off system with a simple pull of a lever
- 2.
4 stretchers.
- 3.
Easily switch from round to square bales by simply lifting a lever to go from a v-strapped bed to a flat bed.
- 4.
Autopilot the automatic pilot system allows the wrapper to precisely steer itself by following the adjacent bale row, maximizing the space needed to store your bales.
- 5.
Remote control for starting, steering, and stopping the unit remotly without leaving the tractor.
- 6.
Large fuel tank (25 L, 6.6 GAL.) wrap 5 times more bales than with regular tank with less down time.
- 7.
Film watch sensor automatically shuts down the wrapping cycle when the machine runs out of film or film breaks.
- 8.
Bale guide rollers keep each bale centered on the roller bed when wrapping on a slope.
- 9.
Hydraulic lifting axles allow to overcome obstacles when moving the machine.
- 10.
20 HP engine.
| Bale | |
|---|---|
| Round bale diameter** | Up to 6 ft (1,8 m) |
| Round bale length | Up to 5 ft (1,5 m) |
| Square bale | 3 ft x 3 ft (80 x 90 cm) nor 4 ft x 3 ft (90 x 120 cm) Up to 6 ft (1,8 m) |
| Wrapping speed* | Up to 180 bales/h |
| Specifications | |
|---|---|
| Aluminum film stretcher | 4 x 30 in (750 mm) |
| Engine | 13 HP Hondan(20 HP optional) |
| Final bale push off | Xtractor™ automatic system |
| Bed shape | Flat or V-shaped for all type bales |
| Bale guides for alignment | Adjustable |
| Bale guides rollers | 2 |
| Leveling system | Hydraulic lifting axle |
| Road lights | Standard |
| Hoop speed | Adj. flow control valve |
| Traction Tires | 29 x 12,5-15 |
| Rear tires | 11L-15 |
| Hydraulic tail gate | Standard |
| Auto-locking wheels | Standard |
| Adjustable hydraulic compaction system | Standard |
| Smart start | Standard |
| Dimensions | |
|---|---|
| Overall width – A | 9 ft 8 in (2,95 m) |
| Overall width (in transport mode) | 8 ft 5 in (2,56 m) |
| Overall height – B | 9 ft 4 in (2,87 m) |
| Overall length | 18 ft 9 in (5,74 m) |
| Overall length (in transport mode) | 16 ft 9 in (5,12 m) |
| Overall weight | 5511 lb (2500 kg) |
| Weight on tow bar | 903 lb (410 kg) |
