Mergepro300
Features and Benefits
Why buy the Mergepro300?
01
COMPACT AND FRONT-MOUNTED
The Advantages of a Front-Mounted Merger
A front-mounted merger provides a cleaner, more efficient way to harvest forage. By merging the crop before the tractor wheels pass over it, it minimizes soil and stone contamination while preserving valuable leaves and forage quality. Its front-mounted position also gives the operator excellent visibility, making it easier to adapt to changing field conditions and produce a consistent windrow. Whether used on its own or paired with a rear merger, a front-mounted merger increases field capacity,
02
FASTEST WORKING SPEED
Camless 6 row pickup reel means, no unnecessary bearings, control rollers, curved tracks and tine carrier profiles. Significantly fewer components for higher working speed and reduced maintenance. Simple rotation, no additional moving parts, no additional wear. Less parts = less maintenance.
Cam less pickup also allows for maximum working speed from 0 to 18 mph (0-28 km/h)
03
ADAPTIVE TRUE-GROUND-TECHNOLOGY
This truly unique feature to the MERGEPRO allows the pickup and belt to be constantly monitoring the ground speed and adjusting themselves to deliver constant and equal crop on the belt as you go insuring consistent swath.
04
DEFLECTOR ABOVE BELT AND PICK-UP
Optimizing the crop upside down rotation for better drying effect of the forage.Ensures constant and smooth flow of the crop from the field ground to the belt conveyor without damaging the leaves or letting them flying off the swath.
05
CROP DELIVERY
Delivery possible on the left and right. Dimension of 9,4 ft (2,87 m).
06
ÉTROIT ET SIMPLE
For the same raking width as a rotary rake, belt rakes are much more compact in size, making them much easier to use and store. Their stability and weight also make them easier for your tractor to lift, making transport and navigation of rough roads simpler and making them ideal for working in tight spaces.
07
HEAVY DUTY BELT CONVEYOR
Commercial-grade belt conveyors provide efficient transition from crop to windrow, regardless of delivery side. The conveyor belt is self-cleaning and requires no tracking adjustments. The belt tension can be adjusted without any tools.
08
FIELD COMPACTION
The large contact surface of the skid shoes ensures, even in very soft and wet soil conditions, that the MERGEPRO glides smoothly over the ground. This support surface has a damping effect and thus reduces system oscillations and vibrations. Low compaction is equally achieved due to our hydraulic adjustable suspension system. This protects the entire system and the field.
MergePro Sizing & Swath Optimization Simulator
Match your merger to your mowing setup.
This tool analyzes your current mowing configuration and swath width to determine which Anderson MergePro model best fits your operation. Optimize working width, field efficiency, and harvest performance with data-driven sizing recommendations.
CLIENT TESTIMONIAL
” The Anderson did things that the Reiter and Oxbo would not have done. our crew has used both machines. the mergepro has Faster ground speed, a cleaner sweep and double merging crossing windrows. It didn’t matter, it just simply went through !”
James Martin, Martin’s Supply LLC. Greencastle, PA
Interested in the Mergepro300?
Technical specifications
Mergepro300
Specifications
| Working width centre swath | N/A |
| Working width side swath | 9,4 pi (2,87 m) |
| Swath width centre swath | N/A |
| Swath width side swath with swathboard | N/A |
| Number of pick-up units | 1 |
| Transport width | 9,9 pi (2,97 m) |
| Transport height | 4,25 pi (1,30 m) |
| Transport length | 7,5 pi (2,29 m) |
| Height in transport position (for shipftng purpose) | 4,25 pi (1,30 m) |
| Min power flat ground (12km/h- 8mph) | 95 hp (71 kw) |
| Min power flat terrain (28km/h -18mph)** | 110 hp (82 kw) |
| Min power all other type of terrain (28km/h-18mph)** | 125 hp (93 kw) |
| PTO requirement | N/A |
| PTO RPM and equivalent optimal working speed | N/A |
| Max working speed | 18 mph (28 km/h) |
| Hydraulic | N/A |
| Conveyor belt hydraulic motor | High quality Hydraulic piston Motor |
| pickup hydraulic motor | Hydraulic motor @ 243 RPM @ 28 km/h (18 mph) |
| Oil reservoir capacity | N/A |
| Oil type | N/A |
| Oil Cooling system | N/A |
| Tires on transport chassis | N/A |
| Conveyor length | 9,5 ft (2,9 m) |
| Conveyor width | 36 po (0,92 m) |
| Discharge capability | right left |
| Conveyor direction control from tractor cab | Standard |
| Pickup height | 0-3 po ( 7,2 cm) |
| Hitch | 2 points Category 2 |
| Electronic variable ftckup speed control from tractor cab | Standard |
| Road lights and signaling | N/A |
| Required tractor hydraulic connections | 1 outlet standard |
| Minimum hydraulic flow rate of the tractor | 21 gal/min (80 l/min) |
| Minimum hydraulic pressure of the tractor | 2800 psi (190 bar) |
| Approximate machine weight | 2610 lb (1184kg) |
| Adjustable skid shoes | Standard |
Comparing ground pressure:
| 1 person weighing 90kg (200 lbs) | 1,16 lbs/po2 ( 0,081 kg/cm2) |
| 1 MergePro skid | 0,85 lb/po2 (0,059 kg/cm2) |
