Back to Trailers

See the TRB1000

The Anderson Group is proud to introduce the world’s first self-loading bale carrier capable of handling efficiently wrapped silage bales.
The RBMPRO series can move nearly twice as many bales as any traditional platform system. It reduces the time spent in the field, the labor, as well as the fuel consumption. This allows more time for the farmer or the contractor to spend it where it counts! Finally, the superior productivity of the RBMPRO series helps to free the field as quickly as the baler passes through it, all without risks of breaking the plastic.

Features and options

  1. 1.

    Possibility of collecting bales on their flat or round side

  2. 2.

    Bale loading speed: 8 minutes 30 sec for 20 bales

  3. 3.

    Unloading in 45 seconds

  4. 4.

    Fully automated (little operator experience required)

  5. 5.

    Touch screen with self-diagnostic system

  6. 6.

    Danfoss hydraulics

  7. 7.

    Patented design

  8. 8.

    Monitoring of customer statistics (ideal for contractors)

Round bale diameterUp to 5 ft (1,5 m)
Square balen/a
Bale typeBaleage/dry hay/straw/ Wrapped bale (min. 6 layers of film)
Tandem axleStandard
Tandem axle with brakesOptional
Self-Steering axle with brakesOptional
Safety chainStandard
Self-loading arm designHydraulic clamp
Able to load a second row of balesTelescopic arm
Caméra (de recul)Standard
Tractor minimum hydraulic flow2800 psi (190 bar)
HP requirements130 HP
Double hydraulic connections required3 + LS
PTO Speed/ PTO shaftN/A
ControlsTouchscreen display
Width – A8 ft 4 in (2,55 m)
Overall width (inlcuding loading arm)8 ft 4 in (2,55 m)
Height – B12 ft 2 in (3.71m)
Overall height (inlcuding loading arm)12 pi 6 po (3.81m)
Bed height - E5 pi (1,55 m)
Overall length – D38 pi 5 po (11,76 m)
Overall weight14 990 lb (6800 kg)
Empty Weight on tow bar***3415 lb (1550 kg)
Round bale 4 ft x 4 ftdiameter (1,2 m x 1,2 m)In 2 rows = 14nIn 3 rows = 19 or 20
Round bale 4 ft x 5 ft diameter (1,2 m x 1,5 m)In 2 rows = 14nIn 3 rows = 19 or 20
Round bale 4 ft x 6 ft diameter (1,2 m x 1,8 m)n/a
Round bale 5 ft x 5 ft diameter (1,5 m x 1,5 m)In 2 rows = 12nIn 3 rows = 16 or 17
Round bale 5 ft x 6 ft diameter (1,5 m x 1,8 m)n/a
Square bale 3 ft x 3 ft x 8 ft long (90 cm x 90 cm x 2,4 m)n/a
Square bale 4 ft x 3 ft x 8 ft long (1,2 m x 90 cm x 2,4 m)n/a
Square bale 4 ft x 4 ft x 8 ft long (1,2 m x 1,2 m x 2,4 m)n/a
Loading arm lifting capacity2500 lb (1135 kg)
Total weight including load42 000 lb (19 000 kg)
Compare Round bales - Round bales

Find the operator's manual
